钣金FIRST机器人底盘（ID:559408）

机械设备 / 智能装置 / 钣金FIRST机器人底盘

167

平面图

3D视图

文件列表

屿双网

#	文件名称	文件大小
1	+必看说明+.txt	2.22 KB
2	7990N123 UHMW Battery Tray.ipt	738 KB
3	9001K49 Aluminum U-Channel.ipt	122 KB
4	9600K610_SBR RUBBER PUSH-IN GROMMET 1.25.ipt	141 KB
5	9600K610_SBR RUBBER PUSH-IN GROMMET 1.25_MIR.ipt	147 KB
6	9600K610_SBR RUBBER PUSH-IN GROMMET 1.25_MIR1.ipt	141 KB
7	9600K890_SBR RUBBER PUSH-IN GROMMET 1.0.ipt	132 KB
8	9600K890_SBR RUBBER PUSH-IN GROMMET 1.0_MIR.ipt	139 KB
9	9600K890_SBR RUBBER PUSH-IN GROMMET 1.0_MIR1.ipt	135 KB
10	Battery 2022.iam	134 KB
11	Battery Assembly.iam	222 KB
12	Battery Mount.ipt	319 KB
13	Bearing, .375 ThunderHex, Flanged, 217-5829.ipt	133 KB
14	Bearing, 6802.ipt	95 KB
15	Bearing, 688.ipt	122 KB
16	Bearing, A035XPO_SA035XPO.ipt	124 KB
17	Bearing, R188ZZ, 217-3489.ipt	80 KB
18	Bearing, R6ZZ.ipt	96 KB
19	Bearing, R8ZZ.ipt	94 KB
20	Belly Pan.ipt	1.03 MB
21	Belt, 320-5M-15.ipt	86 KB
22	Bevel Gear, 1545.ipt	1.15 MB
23	Bevel Gear, 4515.ipt	1.63 MB
24	CANcoder Assembly.iam	383 KB
25	CANcoder Bottom Housing.ipt	264 KB
26	CANcoder PCA.ipt	166 KB
27	CANcoder Screw.ipt	746 KB
28	CANcoder Top Housing.ipt	312 KB
29	Chassis Presentation.ipn	244 KB
30	Chassis Step File.stp	157 MB
31	Chassis.iam	14 MB
32	Chassis.idw	10.7 MB
33	Double Gear, 20DP, 25T, 50T.ipt	606 KB
34	Double Gear, 20DP, 27T, 50T.ipt	614 KB
35	Double Gear, 20DP, 28T, 50T.ipt	750 KB
36	Electrical_Yuasa_NP18-12_Top.ipt	240 KB
37	Electrical_Yuasa_Np18-12_Middle.ipt	97 KB
38	Electronics Plate Assembly.iam	9.66 MB
39	Electronics Plate.ipt	132 KB
40	Falcon Spacer .0625.ipt	79 KB
41	Falcon Spacer .125.ipt	80 KB
42	Falcon Spacer .25.ipt	79.5 KB
43	Frame Representation.ipt	94.5 KB
44	Front Cap.ipt	455 KB
45	Front Spreader Reinforcement.ipt	259 KB
46	Front Spreader.ipt	768 KB
47	Front Tank Assembly.iam	323 KB
48	Gear, 17T, 20DP, .375Hex.ipt	291 KB
49	Gear, 19T, 20DP, .375Hex.ipt	251 KB
50	Gear, 20DP 14T, Falcon Spline, am-4147.ipt	456 KB
51	Gear, 20DP, 16T, .375Hex, 217-5451.ipt	283 KB
52	Gear, 50T, 20DP, .375Hex.ipt	778 KB
53	Left Side 29.5.ipt	1.94 MB
54	Left Side.ipt	1.81 MB
55	MK3 Base Pulley Tall.ipt	573 KB
56	MK3 Center Column.ipt	123 KB
57	MK4 Billet Wheel Assembly.iam	592 KB
58	MK4 Intermediate Shaft.ipt	124 KB
59	MK4 Wheel Spacer.ipt	131 KB
60	MK4i Master Part_Default Falcon 500 Config.ipt	1.55 MB
61	MK4i Shaft, Drive Idler.ipt	106 KB
62	MK4i Steering Shaft Spacer.ipt	80.5 KB
63	MK4i Steering Shaft Tall.ipt	225 KB
64	Master Parameter DO NOT CHANGE.ipt	89.5 KB
65	Motor, Falcon500.ipt	4.99 MB
66	NI roboRIO.ipt	39.5 MB
67	OM5P-AC_Radio.ipt	900 KB
68	REV-11-1850 【屿双网】.STEP	66.3 MB
69	REV-11-1850.ipt	31.2 MB
70	REV-11-1852 【屿双网】.STEP	24.6 MB
71	REV-11-1852.ipt	11.6 MB
72	REV-11-1856 【屿双网】.STEP	12 MB
73	REV-11-1856.ipt	6.01 MB
74	REV-11-1860 【屿双网】.STEP	2.02 MB
75	REV-11-1860.ipt	983 KB
76	REV-11-1861 【屿双网】.STEP	2.46 MB
77	REV-11-1862 【屿双网】.STEP	2.5 MB
78	REV-11-1863 【屿双网】.STEP	2.02 MB
79	Right Side Drive Module.iam	3.48 MB
80	Right Side Drive Module_MIR.iam	379 KB
81	Right Side Drive Module_MIR1.iam	3.29 MB
82	Right Side_MIR.ipt	2.04 MB
83	SDS MK4i Swerve Module, Falcons 【屿双网】.STEP	49.1 MB
84	SDS MK4i Swerve Module, Falcons.iam	353 KB
85	Screw, .25-20 X .625, 91251A539_91251A539.ipt	558 KB
86	Screw, .25-20 X 1 Socket, 91251A542_91251A542.ipt	735 KB
87	Screw, 10-32 X .25, Button, 91255A261_91255A261.ipt	404 KB
88	Screw, 10-32 X .5, Button, 97763A232_97763A232.ipt	565 KB
89	Screw, 10-32 X .75, Button, 91255A269_91255A269.ipt	596 KB
90	Screw, 10-32 X 1.375, 90044A202_90044A202.ipt	677 KB
91	Screw, 10-32 X 2.25, 91251A354_91251A354.ipt	678 KB
92	Screw, 12-24 X .625, Flat, 91253A282_91253A282.ipt	481 KB
93	Screw, 3-48 X .1875, Pan Phillips, 90272A091_90272A091.ipt	527 KB
94	Screw, 8-32 X .875, Button, 91255A166_91255A166.ipt	721 KB
95	Screw, 8-32 X 2.5, 91251A207_91251A207.ipt	723 KB
96	Screw, Falcon 500 Pinion_90939A124.ipt	678 KB
97	Screw, Shoulder, .375 X 2.5, 5_16-18, 91259A634_91259A634.ipt	436 KB
98	Shim, 8mm ID X 14mm OD X .5mm Thick, 98055A115_98055A115.ipt	78 KB
99	Skid Plate-30.ipt	794 KB
100	Skid Plate.ipt	816 KB
101	Talon SRX.ipt	5.53 MB
102	Tank Mount Large Dia.ipt	939 KB
103	Tank Mount Small Dia.ipt	919 KB
104	Tread, Blue Nitrile 4in X 1.5in.ipt	1.3 MB
105	Wheel Mount A.ipt	149 KB
106	Wheel Mount B Gen2.ipt	158 KB
107	Wheel, SDS, Nitrile Tread, 4in X 1.5in, Bearing Bore.ipt	355 KB
108	Wiring DIagram 【屿双网】.dwg	1.43 MB
109	Working Drawings.idw	4.52 MB
110	X_Brace_Side.ipt	405 KB
111	X_Brace_Side_Arch.ipt	272 KB
112	X_Brace_Side_MIR.ipt	326 KB
