961毫米“厄利空”机关枪UG设计（ID:574838）
40
0
0
| # | 文件名称 | 文件大小 |
|---|---|---|
| 1 | 1-2 IPS sq plug.prt | 98 KB |
| 2 | 20 mm cartridge case Mk 3.prt | 450 KB |
| 3 | 20 mm gun A on mt Mk 10-A_igs.prt | 203 KB |
| 4 | 20 mm gun Mk1A-A.prt | 144 KB |
| 5 | 20 mm round AC Mk 1-A.prt | 79 KB |
| 6 | 20 mm round AC Mk 1.prt | 342 KB |
| 7 | 5420421361331.jpg | 48.2 KB |
| 8 | 54204213f21cc.jpg | 61.2 KB |
| 9 | Alemite 1-8.prt | 130 KB |
| 10 | Barrel mod 1-1013.prt | 1.83 MB |
| 11 | Mk 10 mount-A_FORE.prt | 113 KB |
| 12 | Mk 10 mt-ball-3511.prt | 89.5 KB |
| 13 | Mk 10 mt-carriage Mk 5-A_CRADLE LOCKED LOWER.prt | 108 KB |
| 14 | Mk 10 mt-carriage lock ball spring-3516_COMPRESSED.prt | 333 KB |
| 15 | Mk 10 mt-carriage lock lever seal-3519.prt | 1000 KB |
| 16 | Mk 10 mt-carriage lock lever-3512.prt | 219 KB |
| 17 | Mk 10 mt-carriage lock plunger-3515.prt | 168 KB |
| 18 | Mk 10 mt-cradle spring hsg cvr-299788-2.prt | 442 KB |
| 19 | Mk 10 mt-cradle spring hsg-299798.prt | 532 KB |
| 20 | Mk 10 mt-cradle spring hsg-A.prt | 80.5 KB |
| 21 | Mk 10 mt-cradle spring-487478.prt | 242 KB |
| 22 | Mk 10 mt-cradle-A.prt | 88.5 KB |
| 23 | Mk 10 mt-pivot cap-365905-2.prt | 213 KB |
| 24 | Mk 10 mt-pivot hsg draw stud-365905-3.prt | 101 KB |
| 25 | Mk 10 mt-pivot hsg-365904-1.prt | 286 KB |
| 26 | Mk 10 mt-pivot retainer-3504.prt | 158 KB |
| 27 | Mk 10 mt-pivot thrust brg half-299962-3.prt | 109 KB |
| 28 | Mk 10 mt-pivot-365905-1.prt | 242 KB |
| 29 | Mk 10 mt-stand-A.prt | 86 KB |
| 30 | Mk 10 mt-stand.prt | 1.47 MB |
| 31 | Mk 10 mt-trunnion bkt-3520.prt | 2.89 MB |
| 32 | Mk 10 mt-trunnion bkt-A_LOCKED.prt | 84.5 KB |
| 33 | Mk 10 mt-trunnion nut lt-367701.prt | 132 KB |
| 34 | Mk 10 mt-trunnion nut rt.prt | 138 KB |
| 35 | Mk 10 mt-trunnion pin lt-299798-1.prt | 223 KB |
| 36 | Mk 10 mt-trunnion pin rt.prt | 192 KB |
| 37 | Mk 4 mt-cheek pl lt-2074.prt | 199 KB |
| 38 | Mk 4 mt-cheek pl rt-2075.prt | 198 KB |
| 39 | Mk 4 mt-cradle-2325.prt | 1.96 MB |
| 40 | Mk 4 mt-gun lock withdrawing head-2190.prt | 147 KB |
| 41 | Mk 4 mt-gun locking bolt spring-2189_COMPRESSED.prt | 302 KB |
| 42 | Mk 4 mt-gun locking bolt-2188.prt | 168 KB |
| 43 | Mk 4 mt-shield assy.prt | 964 KB |
| 44 | Mk 4 mt-trunnion bkt lock spring-2074_RELEASED.prt | 341 KB |
| 45 | Mk 4 mt-trunnion bkt lock bushing-2071.prt | 179 KB |
| 46 | Mk 4 mt-trunnion bkt lock-A_LOCKED.prt | 80.5 KB |
| 47 | Mk 4 mt-trunnion bkt locking bolt-2070.prt | 225 KB |
| 48 | Mk10 mt-carriage packing-3522.prt | 182 KB |
| 49 | backsight-1176.prt | 407 KB |
| 50 | barrel lock handle catch-1050.prt | 240 KB |
| 51 | barrel lock handle plunger-1051.prt | 96 KB |
| 52 | barrel lock handle spring-1345_RELEASED.prt | 221 KB |
| 53 | barrel lock handle-1049.prt | 198 KB |
| 54 | barrel lock handle-A.prt | 82 KB |
| 55 | barrel lock lever plunger-1070.prt | 104 KB |
| 56 | barrel lock lever spring-1339_RELEASED.prt | 233 KB |
| 57 | barrel locking lever-1078.prt | 186 KB |
| 58 | barrel spring buffer-1057.prt | 210 KB |
| 59 | barrel spring case-1102.prt | 333 KB |
| 60 | barrel spring center sleeve-1325.prt | 118 KB |
| 61 | barrel spring front-1321_RELEASED.prt | 1.46 MB |
| 62 | barrel spring rear-1320_RELEASED.prt | 804 KB |
| 63 | barrel spring seating ring catch spring-1337_RELEASED.prt | 291 KB |
| 64 | barrel spring seating ring catch-1058.prt | 227 KB |
| 65 | barrel spring seating ring-1056.prt | 133 KB |
| 66 | barrel stop pin pl-1059.prt | 89.5 KB |
| 67 | barrel stop pin spring-1331_RELEASED.prt | 216 KB |
| 68 | barrel stop pin-1052.prt | 118 KB |
| 69 | barrel stop plunger-1072.prt | 94 KB |
| 70 | breech bar-left-1310.prt | 457 KB |
| 71 | breech bar-right-1311.prt | 493 KB |
| 72 | breech bolt cotter-1316.prt | 160 KB |
| 73 | breech casing-1040.prt | 1.26 MB |
| 74 | breech casing-A.prt | 124 KB |
| 75 | double loading stop bushing washer-1081.prt | 218 KB |
| 76 | double loading stop bushing-1055.prt | 113 KB |
| 77 | double loading stop lever-1053.prt | 272 KB |
| 78 | double loading stop plunger upper-1080.prt | 93 KB |
| 79 | double loading stop plunger-1069.prt | 102 KB |
| 80 | double loading stop spring-1344_COMPRESSED.prt | 334 KB |
| 81 | double loading stop-1054.prt | 201 KB |
| 82 | ejector-1045.prt | 228 KB |
| 83 | foresight assy-1167.prt | 293 KB |
| 84 | hand grip assy catch plunger--1065.prt | 102 KB |
| 85 | hand grip assy catch spring-1335_RELEASED.prt | 331 KB |
| 86 | hand grip assy catch-1062.prt | 143 KB |
| 87 | hand grip assy catch-A.prt | 80.5 KB |
| 88 | hand grip assy-1710.prt | 1.12 MB |
| 89 | hand grip-A.prt | 80.5 KB |
| 90 | magazine bolt-1556.prt | 94 KB |
| 91 | magazine casing-1544.prt | 160 KB |
| 92 | magazine catch lever axis-1035.prt | 180 KB |
| 93 | magazine catch lever-1043.prt | 363 KB |
| 94 | magazine coupling sleeve-1529.prt | 197 KB |
| 95 | magazine cvr-1581.prt | 848 KB |
| 96 | magazine front pl assy-1531.prt | 1.59 MB |
| 97 | magazine indicatorr-1583.prt | 119 KB |
| 98 | magazine interlock catch-1046.prt | 121 KB |
| 99 | magazine main shaft-1584.prt | 111 KB |
| 100 | magazine mouth piece-1548.prt | 314 KB |
| 101 | magazine rear pl assy-1532.prt | 1.17 MB |
| 102 | magazine spring axis-1582.prt | 249 KB |
| 103 | magazine-A.prt | 98 KB |
| 104 | recoiling mass-A.prt | 86 KB |
| 105 | safe-fire lever plunger-1235.prt | 103 KB |
| 106 | safe-fire lever spring-1328_RELEASED.prt | 330 KB |
| 107 | safe-fire lever-1237.prt | 228 KB |
| 108 | safe-fire lever-A.prt | 80.5 KB |
| 109 | shoulder support assy-left-1733.prt | 556 KB |
| 110 | shoulder support assy-right-1732.prt | 410 KB |
| 111 | sight bar-1175.prt | 470 KB |
| 112 | sight mk 4 bkt-1171.prt | 1.14 MB |
| 113 | sight mk 4-A.prt | 81.5 KB |
| 114 | trigger cvr pl-1233.prt | 192 KB |
| 115 | trigger-1220.prt | 195 KB |
| 116 | zpt.prt | 196 KB |
| 117 | ╨┬╜¿╬─▒╛╬─╡╡.txt | 256 B |
免责申明:
本网站模型由用户自行上传，如权利人发现存在误传其作品情形，请及时与本站联系。
立即下载
此图纸下载需要150金币
图纸ID：574838
文件大小：18.23M
软件版本：UG
图纸格式：prt
参数/编辑：可修改，包括参数
上传时间：2024-06-20
