自行车车架支架（ID:717973）
| # | 文件名称 | 文件大小 |
|---|---|---|
| 1 | .375 flat washer.prt | 148 KB |
| 2 | .375 x 1 hex head bolt.prt | 244 KB |
| 3 | .375 x 1.5 hex head bolt.prt | 244 KB |
| 4 | .5 x 1.5 dowel.prt | 156 KB |
| 5 | .5 x 1.5 hex head bolt.prt | 260 KB |
| 6 | .5 x 2.0 dowel.prt | 156 KB |
| 7 | 1.125_tube_1.prt | 172 KB |
| 8 | 10mm flange nut.prt | 292 KB |
| 9 | 2.5mm spacer.prt | 168 KB |
| 10 | GH-13007_1.prt | 456 KB |
| 11 | SHCS_1_4-28_0375_A.prt | 188 KB |
| 12 | SHCS_1_4-28_0625_A.prt | 180 KB |
| 13 | SHCS_1_4-28_1000_A.prt | 180 KB |
| 14 | angle quandrant.prt | 176 KB |
| 15 | bike jig assembly.prt | 2.23 MB |
| 16 | bike jig.JPG | 21.9 KB |
| 17 | bottom bracket alignment bar.prt | 172 KB |
| 18 | bottom bracket centering cone.prt | 228 KB |
| 19 | bottom bracket jig.prt | 340 KB |
| 20 | drop out jig mounting bracket.prt | 440 KB |
| 21 | dropout jig arm.prt | 456 KB |
| 22 | floor stand pivot.prt | 216 KB |
| 23 | floor stand.prt | 704 KB |
| 24 | frame.prt | 1.68 MB |
| 25 | framejig.prt | 308 KB |
| 26 | ggs_vblock_1.prt | 612 KB |
| 27 | gh-13007a_1.prt | 276 KB |
| 28 | gh-13007b_1.prt | 1.25 MB |
| 29 | gh-13007c_1.prt | 548 KB |
| 30 | head tube alignment bar.prt | 156 KB |
| 31 | head tube angle jig bar.prt | 252 KB |
| 32 | head tube centering cone.prt | 232 KB |
| 33 | head tube jig 2.prt | 292 KB |
| 34 | head tube jig arm.prt | 360 KB |
| 35 | head tube jig mounting arm.prt | 368 KB |
| 36 | head tube jig.prt | 348 KB |
| 37 | head tubet jig mounting bracket.prt | 500 KB |
| 38 | lower tue alignment arm.prt | 240 KB |
| 39 | main plate ggs.prt | 964 KB |
| 40 | main plate.prt | 1010 KB |
| 41 | sinkus_assembly_1.prt | 832 KB |
| 42 | sinkus_mounting_block_1.prt | 448 KB |
| 43 | steer tube centering cone.prt | 224 KB |
| 44 | steering tube jig mounting arm.prt | 372 KB |
| 45 | steering tube jig.prt | 344 KB |
| 46 | tube cenetering clamp.prt | 300 KB |
| 47 | tube centering clamp.prt | 372 KB |
| 48 | tube locating assembly.prt | 788 KB |
| 49 | tube locating block.prt | 488 KB |
| 50 | zongzhuangtu.stp | 6.12 MB |
| 51 | zongzhuangtu.x_t | 6.66 MB |
免责申明:
本网站模型由用户自行上传，如权利人发现存在误传其作品情形，请及时与本站联系。
立即下载
此图纸下载需要20金币
图纸ID：717973
文件大小：11.63M
软件版本：STP,PARASOLID,UG
图纸格式：prt,x_t
参数/编辑：可修改，包括参数
上传时间：2025-03-28
