DIY雕刻机（数控裁布机）（ID:731453）
125
0
0
| # | 文件名称 | 文件大小 |
|---|---|---|
| 1 | 19x19 1200mm steel cube support.SLDPRT | 67.1 KB |
| 2 | 19x19 1260mm y rail axis.SLDPRT | 54.1 KB |
| 3 | 19x19 800mm rail x.SLDPRT | 56 KB |
| 4 | 19x19 800mm steel cube.SLDPRT | 71.8 KB |
| 5 | Assem2 cnc model4.SLDASM | 6.48 MB |
| 6 | Limit switch.SLDPRT | 213 KB |
| 7 | Linear Bearing.SLDPRT | 111 KB |
| 8 | Nema17 bracket cnc final.SLDPRT | 119 KB |
| 9 | Part3 cnc big.SLDPRT | 62.2 KB |
| 10 | Part9^assembly cnc 4 idler spacer.SLDPRT | 91.7 KB |
| 11 | V-Wheel_Ø24.4mm.SLDPRT | 158 KB |
| 12 | a axis rotate 2.SLDASM | 1.34 MB |
| 13 | aluminium spacer washer bore6mm d10mm l10mm.SLDPRT | 90.5 KB |
| 14 | aluminium spacer washer bore6mm d10mm l30mm.SLDPRT | 100 KB |
| 15 | bearing608nse.SLDPRT | 105 KB |
| 16 | belt tension adjust 1.SLDPRT | 69 KB |
| 17 | belt tension adjust 2top.SLDPRT | 48.9 KB |
| 18 | box controller.SLDPRT | 276 KB |
| 19 | carbon steel 8mm 230mmL (1).SLDPRT | 39.8 KB |
| 20 | carbon steel 8mm 230mmL.SLDPRT | 40.3 KB |
| 21 | connect plate in X move.SLDPRT | 90.6 KB |
| 22 | coupling 1.SLDPRT | 93.9 KB |
| 23 | esteira 15mm meio.SLDPRT | 494 KB |
| 24 | esteira 15mm ponta.SLDPRT | 243 KB |
| 25 | esteira assy eixo y.SLDASM | 264 KB |
| 26 | flat x motor 2small.SLDPRT | 64 KB |
| 27 | flat x motor.SLDPRT | 503 KB |
| 28 | frame width800.SLDPRT | 79.8 KB |
| 29 | frame lenght 1200mm.SLDPRT | 60.4 KB |
| 30 | hex nut style 2_am m5.SLDPRT | 205 KB |
| 31 | hex nut style 2_am.sldprt | 306 KB |
| 32 | idler pulley 20T.SLDPRT | 94.5 KB |
| 33 | knife circle drag.SLDPRT | 144 KB |
| 34 | knife support bearing.SLDPRT | 130 KB |
| 35 | lead screw driven nut m8.SLDPRT | 82.1 KB |
| 36 | lead screw m8.SLDPRT | 2.12 MB |
| 37 | lead screw.SLDPRT | 82.7 KB |
| 38 | linear pipe shafe support.SLDPRT | 92 KB |
| 39 | linear shaft support.SLDPRT | 90.4 KB |
| 40 | motor z mount part.SLDPRT | 102 KB |
| 41 | nema17 cnc me.SLDPRT | 1.1 MB |
| 42 | pipe fix on frame plate 10mm.SLDPRT | 96.3 KB |
| 43 | shaft mount 8mm.SLDPRT | 92.9 KB |
| 44 | socket head cap screw_am 25mm.SLDPRT | 326 KB |
| 45 | spacer 45mm h.SLDPRT | 36.3 KB |
| 46 | spring 1.SLDPRT | 500 KB |
| 47 | stepp motor.SLDPRT | 88.3 KB |
| 48 | timming pulley 20T.SLDPRT | 107 KB |
| 49 | washer 6mmbore D12 t1mm.SLDPRT | 56.9 KB |
| 50 | y plate move back (1).SLDPRT | 77.1 KB |
| 51 | y plate move back.SLDPRT | 127 KB |
| 52 | y plate move front (1).SLDPRT | 63.5 KB |
| 53 | y plate move front.SLDPRT | 128 KB |
| 54 | yAxis support frame new20x20.SLDPRT | 293 KB |
| 55 | z axis plate mount (1).SLDPRT | 55.9 KB |
| 56 | z axis plate mount stepper.SLDPRT | 97.1 KB |
| 57 | z axis plate mount.SLDPRT | 51.5 KB |
| 58 | zongzhuangtu.x_t | 6.13 MB |
免责申明:
本网站模型由用户自行上传，如权利人发现存在误传其作品情形，请及时与本站联系。
立即下载
此图纸下载需要36金币
图纸ID：731453
文件大小：19.68M
软件版本：SOLIDWORKS 2017,PARASOLID
图纸格式：sldprt,sldasm,x_t
参数/编辑：可修改，包括参数
上传时间：2025-04-13
