Bruta 3-自制3D打印机（ID:731505）

数码电器 / 其它电器 / Bruta 3-自制3D打印机

平面图

3D视图

文件列表

屿双网

屿双网

#	文件名称	文件大小
1	3030 corner bracket.sldprt	96.5 KB
2	3030_fixador_reto.sldprt	110 KB
3	3030_fixador_reto_externo.sldprt	112 KB
4	3030_fixador_reto_externo_MIR.sldprt	112 KB
5	608 Ball^608.sldprt	57.5 KB
6	608 Inner Race^608.sldprt	92.5 KB
7	608 Outer Race^608.sldprt	110 KB
8	608.sldasm	64.5 KB
9	Aluminium profile 30x30x300 .sldprt	428 KB
10	Aluminium profile 30x30x380 .sldprt	429 KB
11	Aluminium profile 30x30x500 .sldprt	428 KB
12	Assembly1.sldasm	52.5 KB
13	Ball retainer rings^608.sldprt	783 KB
14	Bearing Ball, GT2 Timing Idler Pulley, Configurable_1 mm.sldprt	59 KB
15	Bearing Inner Ring, GT2 Timing Idler Pulley, Configurable_3 mm Bore, 6 mm OD.sldprt	77 KB
16	Bearing Outer Ring, GT2 Timing Idler Pulley, Configurable_3 mm Bore, 6 mm OD.sldprt	77 KB
17	Bearing Seal, GT2 Timing Idler Pulley, Configurable_3 mm Bore, 6 mm OD.sldprt	77 KB
18	Bearing Subassy, GT2 Timing Idler Pulley, Configurable_3 mm Bore, 6 mm OD.sldasm	76.5 KB
19	Body, GT2 Timing Idler Pulley, Configurable_16T W6 B3 With T.sldprt	563 KB
20	Bruta_V3.err	3.89 KB
21	Bruta_V3.sldprt-dtk.xml	239 KB
22	Capa_Rolamento_608ZZ.sldprt	95.5 KB
23	E3D_v5_Hotend_Assembly v3_ E3D v5 Assembly_1_ Body6.sldprt	258 KB
24	E3D_v5_Hotend_Assembly v3_ E3D v5 Assembly_1_ Body7.sldprt	119 KB
25	E3D_v5_Hotend_Assembly.sldasm	60.5 KB
26	Eixo_retificado_3x20.sldprt	61.5 KB
27	Eixo_retificado_8x30.sldprt	61.5 KB
28	Eixo_retificado_8x300.sldprt	61.5 KB
29	Eixo_retificado_8x320.sldprt	71.5 KB
30	Eixo_retificado_8x500.sldprt	61.5 KB
31	Extruder Nozzle.sldprt	182 KB
32	Flexible Shaft Coupling.sldprt	218 KB
33	GT2 Timing Idler Pulley, Configurable, 16T W6 B3 With T.sldasm	60.5 KB
34	Guia_de_ar.sldprt	199 KB
35	Heat Block.sldprt	146 KB
36	HolderMainBackCover.SLDPRT	54.9 KB
37	Lead Screw D8-P2-L290 (ACME).sldprt	6.81 MB
38	Lm8uu.sldprt	138 KB
39	Logo.sldprt	284 KB
40	MDF-250x250x15.sldprt	67 KB
41	MK8_Ekruder.sldasm	59 KB
42	MK8_Exruder_001.sldprt	123 KB
43	MK8_Exruder_002.sldprt	79 KB
44	MK8_Exruder_003.sldprt	114 KB
45	MK8_Exruder_004(yay).sldprt	79.5 KB
46	MK8_Exruder_005.sldprt	75 KB
47	MK8_Exruder_006.sldprt	483 KB
48	MK8_Extruder.sldasm	57.5 KB
49	Nema_17_Smaller_37mmiam.sldasm	58 KB
50	Nut_8mm_2mm.sldprt	210 KB
51	SCS8UU Anel de Vedação.sldprt	75.5 KB
52	SCS8UU.sldasm	56.5 KB
53	SCS8UU.sldprt	160 KB
54	STEP MOTOR PART 5.sldprt	278 KB
55	Step motor part 1.sldprt	116 KB
56	Step motor part 2.sldprt	183 KB
57	Suport_cooler_ed3_v5.sldprt	441 KB
58	Suporte_rolo_filamento.sldprt	133 KB
59	Suporte_rolo_filamento_MIR.sldprt	133 KB
60	Switch.sldprt	624 KB
61	Tampas_perfil_30x30.sldprt	158 KB
62	Throat.sldprt	373 KB
63	X_Axis_Extrusora_cart.sldprt	299 KB
64	X_Axis_Stopper_new.sldprt	153 KB
65	X_Axis_Suporte_correia_v2.sldprt	388 KB
66	X_Axis_Suporte_extrusora.sldprt	147 KB
67	X_Axis_Suporte_extrusora_Clamp.sldprt	119 KB
68	X_Axis_Suporte_motor.sldprt	432 KB
69	X_Axis_Tensionador_correita.sldprt	178 KB
70	X_Axis_Tensionador_correita_externo.sldprt	158 KB
71	X_Frame.sldasm	95.5 KB
72	Y_Axis_Belt_clamp.sldprt	190 KB
73	Y_Axis_Motor_Support_2.sldprt	133 KB
74	Y_Axis_Stopper.sldprt	90 KB
75	Y_Axis_shaft_support.sldprt	96.5 KB
76	Y_Axis_shaft_support_top.sldprt	125 KB
77	Y_Frame.sldasm	109 KB
78	Y_Suporte_rolamento.sldprt	126 KB
79	Y_Suporte_rolamento_clamp.sldprt	107 KB
80	Z_Axis_Motor_Support.sldprt	178 KB
81	Z_Axis_Motor_Support_MIR.sldprt	178 KB
82	Z_Axis_Stopper_Regulagem_base.sldprt	186 KB
83	Z_Axis_Stopper_new.sldprt	134 KB
84	Z_Axis_Stopper_new_parafuso.sldprt	135 KB
85	Z_Axis_TOP_Perfil_fix_side_2.sldprt	180 KB
86	Z_Axis_TOP_Perfil_fix_side_2_MIR.sldprt	180 KB
87	Z_Axis_locker.sldprt	86.5 KB
88	Z_Frame.sldasm	106 KB
89	placa_aquecida-214x214.sldprt	67 KB
90	step motor orta parça.sldprt	92.5 KB
91	step motor part 4.sldprt	77.5 KB
92	总装配图Bruta_V3.sldasm	2.85 MB
